seawater and brackish water RO-X type Reverse Osmosis Water treatment System for drinking water
1.description
RO-X type reverse osmosis water treatment system has movable type(RO-XM) and engineering type(RO-XE), movable type is used in vehicle and ship, such as business ship, drilling platform. engineering plant is used in island, station, high salt area, sea water encroaching area.
using high technical American RO membrane ,high pressure vessel, high pressure pump, with high efficient pre-treatment system, RO-X type reverse osmosis water treatment system can remove mineral salt, heavy metal ion, organics, bacterium and germs in seawater and make the water reach at the stander of national life drinking water.
2.treatment process
Raw water----raw water pump--- sterilization device-----multi medium filter--- quartz sand filter---precision filter----high pressure pump---RO system----ozone generator/UV---pure water tank
3.operating parameter
Production capacity:0.75m3/H-100m3/H.set
Rate of desalination:99%
Run pressure:4MPa-7MPa
Rate of recovery:10%-40%
Seawater Temperature:2C-40C
4.type and specification
ModelNo. |
Capacity (M3/d) |
Powerof motor (kw) |
weight (kg) |
Size: LX W X H (mm) |
RO-XM-75 |
750 |
22 |
69 |
8500X6000X4700 |
RO-XM-150 |
1500 |
22 |
72 |
8500X6000X4700 |
RO-XM-300 |
3000 |
4.0 |
88 |
15000X6000X4700 |
RO-XM-600 |
6000 |
4.0 |
100 |
15000X6000X4700 |
RO-XM-750 |
7500 |
4.8 |
135 |
15000X6000X4700 |
RO-XM-1500 |
15000 |
4.8 |
270 |
15000X6000X4700 |
RO-XE-30 |
30 |
3.8 |
600 |
3650X1220X1500 |
RO-XE-45 |
45 |
3.8 |
800 |
3650X1220X1500 |
RO-XE-100 |
100 |
3.5 |
1500 |
3650X800X2200 |
RO-XE-500 |
500 |
3.2 |
2500 |
7500X1400X2200 |
RO-XE-1000 |
1000 |
3.0 |
4500 |
7200X2000X2200 |
